OAK DRAW 519

EVAPORATIVE LUBRICANT



DESCRIPTION



OAK DRAW 519 is an “evaporative” lubricant developed for can lids, pre-painted metal stamping and related industries.



APPLICATION



OAK DRAW 519 is primarily used to stamp, bend and form where post cleaning is prohibited.



The “evaporative” nature of this unique lubricant supplies high boundary lubrication, without leaving unsightly residues that interfere with subsequent assembling and/or manufacturing processes.



FEATURES & BENEFITS



CLEANLINESS:



“Evaporates” at room temperature after use, requiring no post cleaning. Clean running product that does not contain oil. Dry-to-touch on pre-painted alloys.



CORROSION:



Non-staining to aluminum and aluminum alloys.



ECONOMICAL:



Contains no water to promote rancidity, thereby ensuring optimum shelf-life in lubricant reservoirs. Low end use cost.



MEETS FOLLOWING FDA REQUIREMENTS:



FDA-CFR 21, 175.105

176.200

176-210(d)(2)

176-210(d)(3)

177.1200

178.3120

178.3910



RECOMMENDED STARTING DILUTIONS



OAK DRAW 519 is used as received (100%) and may be applied by spray, dip or brush methods. Add no other materials to the concentrate unless approved by your CIMCOOL representative.



TYPICAL PHYSICAL AND CHEMICAL PROPERTIES



Physical State	Liquid
Appearance and Odor	Clear/Nearly Odorless
Solubility in water	Insoluble
Weight, lb/gal, 60°F (15.6°C)	6.33
Specific Gravity	0.80
Viscosity SUS @ 100 F	33
Flash Point /Sp.Gr./Boiling Point	SEE MSDS
pH Concentrate	NA
pH, Typical Operating 100%	NA
Total Chlorine/Chlorides, wt%	0/0 ppm
Total Sulfur, wt%	0
Silicones	None



HANDLING AND STORAGE



If frozen, product separates, Thaw completely at room temperature and stir thoroughly prior to use. Inside storage is recommended.



SAFETY DATA SHEET



Available at www.cimcool.com



For additional information refer to its OSHA MSDS, website or contact your local CIMCOOL TECHNICAL SPECIALIST OR DISTRICT MANAGER, or you may contact CIMCOOL® Technical Services at 1-513-458-8199.



Limitation of Liability: Under no circumstances, shall we or any affiliate of ours have any liability whatsoever for loss of use, or for any indirect or consequential damages. Minor formulation changes or normal variations in the manufacture of this product may cause slight variances in the data presented on this sheet.
