OAK 50-5 LA

EVAPORATIVE LUBRICANT



DESCRIPTION



OAK 50-5 LA is an “evaporative” lubricant developed for fin stamping and drawing in the air conditioning and heat transfer industries.



APPLICATION



OAK 50-5 LA is primarily used to stamp and draw aluminum sheet stock where post cleaning is prohibitive.



OAK 50-5 LA has been specifically designed to have low levels of formate and acetate generation when hydrolyzed. This is believed to reduce the chance of formicary corrosion.



FEATURES & BENEFITS



LUBRICITY:



High boundary lubrication, without leaving excessive residues. Has been pre-tested on fin lines around the world, providing good die and tool life.



CLEANLINESS:



“Evaporates” at room temperature after use so parts may not require post cleaning. Clean-running product that does not contain oil.



CORROSION:



Non-staining to aluminum and copper alloys.



ECONOMICAL:



Contains no water to promote rancidity, thereby ensuring optimum shelf-life in lubricant reservoirs. Low end use cost.



RECOMMENDED STARTING DILUTIONS



OAK 50-5 is used as received (100%) and may be applied by spray, dip or brush methods. Add no other materials to the concentrate unless approved by your CIMCOOL representative.



TYPICAL PHYSICAL AND CHEMICAL PROPERTIES



Physical State	Liquid
Appearance and Odor	Clear/Chemical
Solubility in water	Insoluble
Weight, lb/gal, 60°F (15.6°C)	6.5
Specific Gravity	0.80
Viscosity SUS @ 100 F	33
Flash Point /Sp.Gr./Boiling Point	SEE MSDS
pH Concentrate	NA
pH, Typical Operating 100%	NA
Total Chlorine/Chlorides, wt%	0/0 ppm
Total Sulfur, wt%	0
Silicones	None



HANDLING AND STORAGE



If frozen, product separates, Thaw completely at room temperature and stir thoroughly prior to use. Inside storage is recommended.



SAFETY DATA SHEET



Available at www.cimcool.com



For additional information refer to its OSHA MSDS, website or contact your local CIMCOOL TECHNICAL SPECIALIST OR DISTRICT MANAGER, or you may contact CIMCOOL® Technical Services at 1-513-458-8199.



Limitation of Liability: Under no circumstances, shall we or any affiliate of ours have any liability whatsoever for loss of use, or for any indirect or consequential damages. Minor formulation changes or normal variations in the manufacture of this product may cause slight variances in the data presented on this sheet.
