OAK 11B-LA

METALWORKING OIL



DESCRIPTION



OAK 11B LA is a metalworking oil with a polymeric-based expanding, bending and forming lubricant developed to meet the product and process requirements of the air conditioning and heat transfer industries.



OAK 11B LA lubricant has been specifically designed to have low levels of formate and acetate generation when hydrolyzed. This is believed to reduce the chances of formicary corrosion.



APPLICATION



OAK 11B LA has been chemically engineered to form copper tubing on hairpin benders, return benders, straight tube cut-offs and expanders.



Customer will need to confirm compatibility with entire installed working unit.



FEATURES & BENEFITS



LUBRICITY:



Outstanding hydrodynamic and boundary lubrication to maximize formability. Pre-tested on our machinery under “real world” working conditions.



CLEANLINESS:



Does not require post cleaning or leave heavy deposits on machine parts or tooling. Contains no mineral oils, solvents or hazardous materials. Low levels of acetate and formate generation.



ASH LESS:



Contains ash less ingredients to ensure excellent brazing.



CORROSION:



Non-staining to copper and cuprous alloys.



ECONOMICAL:



Contains no water to promote rancidity, thereby ensuring optimum shelf life in lubricant reservoirs.



RECOMMENDED STARTING DILUTIONS



OAK 11B LA is used as received (100%) and may be applied by spray, dip or brush methods. Add no other materials to the concentrate unless approved by your CIMCOOL representative.



TYPICAL PHYSICAL AND CHEMICAL PROPERTIES



Physical State	Liquid
Appearance and Odor	Clear/Chemical
Solubility in water	Insoluble
Weight, lb/gal, 60°F (15.6°C)	6.8
Specific Gravity	0.82
Viscosity SUS @ 100 F	90
Flash Point /Sp.Gr./Boiling Point	SEE MSDS
pH Concentrate	NA
pH, Typical Operating 100%	NA
Total Chlorine/Chlorides, wt%	0/0 ppm
Total Sulfur, wt%	0
Silicones	None



HANDLING AND STORAGE



If frozen, product separates, Thaw completely at room temperature and stir thoroughly prior to use. Inside storage is recommended.



SAFETY DATA SHEET



Available at www.cimcool.com



For additional information refer to its OSHA MSDS, website or contact your local CIMCOOL TECHNICAL SPECIALIST OR DISTRICT MANAGER, or you may contact CIMCOOL® Technical Services at 1-513-458-8199.



Limitation of Liability: Under no circumstances, shall we or any affiliate of ours have any liability whatsoever for loss of use, or for any indirect or consequential damages. Minor formulation changes or normal variations in the manufacture of this product may cause slight variances in the data presented on this sheet.
