MILFORM OAK DRAW 508

EVAPORATIVE LUBRICANT



DESCRIPTION



OAK DRAW 508 is a heavy-duty, “evaporative” fin stamping and collar drawing lubricant developed specifically for the air conditioning and heat transfer industries.



APPLICATION



OAK DRAW 508 is best when production demands require higher and/or unusual collar configurations. It is primarily used on aluminum substrates but will perform other light to moderate-duty forming operations on ferrous metals as well.



OAK DRAW 508 combines high boundary lubrication and extreme pressure additives to offer the ultimate collar drawing product without the use of oil.



FEATURES & BENEFITS



LUBRICITY:



Has been pre-tested on fin lines around the world, providing good die and tool life. Ideally suited for drawing unusual collar configurations.



CLEANLINESS:



After use, parts may not require post cleaning. Clean running product that does not contain oil.



CORROSION:



Non-staining to aluminum alloys and ferrous metals.



ECONOMICAL:



Contains no water to promote rancidity, thereby ensuring optimum shelf-life in lubricant reservoirs. Low end use cost.



RECOMMENDED STARTING DILUTIONS



OAK DRAW 508 is used as received (100%) and may be applied by spray, dip or brush methods. Add no other materials to the concentrate unless approved by your CIMCOOL representative.



TYPICAL PHYSICAL AND CHEMICAL PROPERTIES



Physical State	Liquid
Appearance and Odor	Clear/Chemical
Solubility in water	Insoluble
Weight, lb/gal, 60°F (15.6°C)	6.48
Specific Gravity	0.80
Viscosity SUS @ 100°F	40
Flash Point /Sp.Gr./Boiling Point	SEE MSDS
pH Concentrate	NA
pH, Typical Operating 100%	NA
Total Chlorine/Chlorides, wt%	0/0 ppm
Total Sulfur, wt%	0
Silicones	None



HANDLING AND STORAGE



If frozen, product separates, Thaw completely at room temperature and stir thoroughly prior to use. Inside storage is recommended.



SAFETY DATA SHEET



Available at www.cimcool.com



For additional information refer to its OSHA MSDS, website or contact your local CIMCOOL TECHNICAL SPECIALIST OR DISTRICT MANAGER, or you may contact CIMCOOL® Technical Services at 1-513-458-8199.



Limitation of Liability: Under no circumstances, shall we or any affiliate of ours have any liability whatsoever for loss of use, or for any indirect or consequential damages. Minor formulation changes or normal variations in the manufacture of this product may cause slight variances in the data presented on this sheet.
