CIMSTAR 66

SEMI-SYNTHETIC, METALWORKING FLUID CONCENTRATE



APPLICATIONS



CIMSTAR® 66 is recommended for general purpose machining and grinding of ferrous metals. Can also be used on some applications on nonferrous metals.



Metals: Cast Iron, Nodular Iron, Carbon Steels, High Speed Steel, High Alloy Steels, Stainless Steels, Aluminum



Duty Range: For moderate to heavy duty operations



FEATURES & BENEFITS



CIMSTAR® 66 is designed to be used in metalworking fluid systems with high water hardness (i.e. greater than 400 ppm total hardness).



LUBRICITY:



Physical and chemical lubricants provide good machining and grinding properties - Keeps parts and tools cool



EXCEPTIONALLY MILD:



Ideal for individual machine applications - Can also be used in central systems



EXCELLENT FERROUS CORROSION CONTROL:



Rust inhibitor package is extremely effective in preventing in-process rust on machines and parts Also effective on cast/malleable/gray/nodular irons



NON-FERROUS CORROSION CONTROL:



Contains non-ferrous corrosion inhibitors which prevent stain on many aluminum alloys



SUPERIOR RANCIDITY CONTROL:



Effective protection against bacteria and mold



GENERAL PURPOSE PRODUCT:



Can be used economically throughout the shop on light, moderate and some heavy duty operations; just vary the dilution to suit the job requirements



MACHINE FRIENDLY:



Liquid residue keeps machine tool components free moving



STARTING DILUTIONS



RECOMMENDED FOR INDUSTRIAL USE ONLY



Recommended Starting Dilution	5% (1:20)
Typical Operating Range	5% (1:20) to 10% (1:10)



CIMSTAR® 66 is to be mixed with water for use (add concentrate to water). Add no other substances to the concentrate or mix unless approved by CIMCOOL® Technical Services.



Not recommended for use with magnesium or alloyed magnesium.



For concentration analysis, use the MI Titration Procedure, Non-Solvent Titration Procedure, Total Alkalinity Titration Procedure, CIMCHEK™ Test Strip, or Refractometer.



REFRACTOMETER FACTOR = 1.6 Multiply the scale reading obtained on your CIMCOOL® Metalworking Fluid or other acceptable refractometer by the Refractometer Factor to obtain the mix concentration in percent.



NOTE: Calibrate the refractometer so that it reads 0.0 with water, before testing the sample mix. Remove gross contaminants from the sample mix before testing.



TYPICAL PHYSICAL AND CHEMICAL PROPERTIES



TYPICAL Physical state	Liquid
PHYSICAL AND Appearance and odor	Clear / Chemical
CHEMICAL Colors available	Undyed
PROPERTIES Solubility in water	100% Miscible
Weight, lb/gal, 60°F (15.6°C)	8.12
Specific gravity, (H2O = 1)	0.9726
Boiling point, °F (°C)	212 (100)
Flash point, COC, °F (°C)	None, Self Extinguishing
Fire point, COC, °F (°C)	None, Self Extinguishing
Freezing point, °F, (°C)	30 (-1)
pH, concentrate	10.0
pH, 5.0% mix, typical operating conditions	9.4
Total chlorine/chloride, wt%, calculated	0.00 / < 50 ppm
Total sulfur, wt%, calculated	0.20
Silicones	None



HANDLING:



If frozen, product separates. Thaw completely at room temperature and stir thoroughly.



SAFETY DATA SHEET:



Available at www.cimcool.com



For additional information refer to its OSHA SDS, website or contact your local CIMCOOL TECHNICAL SPECIALIST OR DISTRICT MANAGER, or you may contact CIMCOOL® Technical Services at 1-888-CIMCOOL.



Limitation of Liability: Under no circumstances, shall we or any affiliate of ours have any liability whatsoever for loss of use, or for any indirect or consequential damages. Minor formulation changes or normal variations in the manufacture of this product may cause slight variances in the data presented on this sheet.
