CIMFREE VG-990M

METALWORKING FLUID



DESCRIPTION



CIMFREE VG-990M is a vegetable-based metalworking fluid.



APPLICATION



CIMFREE VG-990M is recommended for a wide variety of moderate duty machining and grinding applications such as milling, drilling, turning and ID and OD grinding.



METALS



Can be used on a wide variety of materials such as carbon steels, high speed steels, cast steels, stainless steels, aluminum, copper and brass.



It should not be used on magnesium.



FEATURES & BENEFITS:



ENVIRONMENTALLY FRIENDLY



Product formula is derived from natural, renewable resources and does not contain mineral oil.



FOAM CONTROL



CIMFREE VG-990M has good foam control, even in soft water.



LUBRICITY



The product exhibits very good lubricity characteristics.



BIOLOGICAL CONTROL



CIMFREE VG-990M has very good biological protection if properly maintained.



RECOMMENDED STARTING DILUTIONS



CIMFREE VG-990M is to be mixed with water for use. Always add concentrate to water. Fluid may be more difficult to mix when water temperature is below 55 F (13 C). Add no other materials to the concentrate or mix unless approved by your CIMCOOL® District Manager.



Grinding	5% - 10% (1:20 to 1:10)
Machining	5% - 10% (1:20 to 1:10)



CONCENTRATION



Total Alkalinity, CIMCHEK™ Test Strip or Refractometer can be used.



The Refractometer Factor is 1.9.



Multiply the scale reading obtained on your CIMCOOL® Refractometer by this factor to obtain the mix concentration in percent. Calibrate the refractometer so that it reads 0.0 with water before testing the sample mix. Remove gross contaminants from the sample mixes before testing. A refractometer is only recommended for use in checking the concentration on a fresh charge.



TYPICAL PHYSICAL AND CHEMICAL PROPERTIES



Physical State	Liquid
Appearance and Odor	Clear /Chemical
Solubility in water	100% miscible
Weight, lb/gal, 60°F (15.6 °C)	8.6
Viscosity (SUS) @ 100°F	500
Flash Point /Sp.Gr./Boiling Point	SEE MSDS
pH Concentrate	10.1
pH Mix 5%, Typical Operating	9.1
Total Chlorine/Chloride, wt%	0.0/<50ppm
Total Sulfur, wt%	0.3
Silicones	No



HANDLING and STORAGE



If frozen, product separates. Thaw completely at room temperature and stir. Inside storage is recommended.



SAFETY DATA SHEET



Available at www.cimcool.com



For additional information refer to its OSHA MSDS, website or contact your local CIMCOOL TECHNICAL SPECIALIST OR DISTRICT MANAGER, or you may contact CIMCOOL® Technical Services at 1-513-458-8199.



Limitation of Liability: Under no circumstances, shall we or any affiliate of ours have any liability whatsoever for loss of use, or for any indirect or consequential damages. Minor formulation changes or normal variations in the manufacture of this product may cause slight variances in the data presented on this sheet.
