CIMFREE VG-703ES
Ships in 5-7 Business Days
METALWORKING FLUID
DESCRIPTION
CIMFREE VG-703ES is a vegetable-based metalworking oil.
APPLICATION
CIMFREE VG-703ES is designed for use in misting applications or other Minimal Quantity Lubrication (MQL) applications where minimal/ low flow volumes are required. It is recommended for machining operations on most ferrous and aluminum operations such as milling drilling, turning, and sawing.
FEATURES & BENEFITS
APPLICATION:
Suitable for use in all type of mist / minimal quantity lubricator application devices.
ENVIRONMENTALLY FRIENDLY:
Product formula is derived from natural, renewable resources and does not contain mineral oil.
ECONOMICAL:
Minimal Quantity Lubricators applying fluid directly to parts minimize quantities of fluid used. Eliminates recharge and disposal costs associated with recirculating systems.
CLEANLINESS:
Finished parts and chips come away almost dry. No need for the fluid to be collected and re-circulated or recycled. Low mist, low odor, low residue keeps work area clean.
Parts are easily cleaned with a mild alkaline cleaner.
LUBRICITY:
Low cutting force – Contains a non-chlorinated, non-sulfurized lubricity agent. These additives provide long tool life and quality part finish.
RECOMMENDED STARTING DILUTIONS
CIMFREE VG-703ES is used neat (100%). Add no other materials to the concentrate or mix unless approved by your CIMCOOL® District Manager.
TYPICAL PHYSICAL AND CHEMICAL PROPERTIES
|
Physical State |
Liquid |
|
Appearance and Odor |
Clear /Chemical |
|
Solubility in water |
Insoluble |
|
Weight, lb/gal, 60°F (15.6 °C) |
7.5 |
|
Viscosity (SUS) @ 100°F |
50 |
|
Flash Point /Sp.Gr./Boiling Point |
SEE MSDS |
|
pH Concentrate |
NA |
|
pH Mix 5%, Typical Operating |
NA |
|
Total Chlorine/Chloride, wt% |
0.0/<50ppm |
|
Total Sulfur, wt% |
0 |
|
Silicones |
No |
HANDLING and STORAGE
If frozen, thaw completely at room temperature. Inside storage is recommended.
SAFETY DATA SHEET
Available at www.cimcool.com
For additional information refer to its OSHA MSDS, website or contact your local CIMCOOL TECHNICAL SPECIALIST OR DISTRICT MANAGER, or you may contact CIMCOOL® Technical Services at 1-513-458-8199.
Limitation of Liability: Under no circumstances, shall we or any affiliate of ours have any liability whatsoever for loss of use, or for any indirect or consequential damages. Minor formulation changes or normal variations in the manufacture of this product may cause slight variances in the data presented on this sheet.
| Manufacturer | CIMCOOL |
|---|
